MICRO晶振|OM-0100-C7-20ppm-TA-QC|低頻SMT振蕩器

  • 頻率：100KHz
  • 尺寸：3.2×1.5mm
  • 應　用： MICRO晶振,OM-0100-C7進口有源晶振,低頻SMT振蕩器,OM-0100-C7-20ppm-TA-QC晶振,貼片石英晶振,晶體振蕩器,3215mm晶振,四腳貼片晶振,頻率100KHz,電壓1.2~5.5V,工作溫度-40~85°C,頻率容差20ppm,低功耗晶振,高抗沖擊晶振...
  • RoHS RoHS2


MICRO晶振|OM-0100-C7-20ppm-TA-QC|低頻SMT振蕩器,MICRO晶振,OM-0100-C7進口有源晶振,低頻SMT振蕩器,OM-0100-C7-20ppm-TA-QC晶振,貼片石英晶振,晶體振蕩器,3215mm晶振,四腳貼片晶振,頻率100KHz,電壓1.2~5.5V,工作溫度-40~85°C,頻率容差20ppm,低功耗晶振,高抗沖擊晶振,高抗振動晶振,筆記本電腦晶振,可穿戴設備晶振,智能手機晶振,FPGA/ASIC時鐘生成晶振.
MICRO晶振|OM-0100-C7-20ppm-TA-QC|低頻SMT振蕩器特點：
•寬電源電壓范圍
•非常低的功耗
•CLKOUT啟用/禁用
•小尺寸，低輪廓，重量輕(10.6毫克)
•高抗沖擊和抗振動
•100%不含鉛，符合RoHS標準
•具備AEC-Q200汽車資質


MICRO晶振|OM-0100-C7-20ppm-TA-QC|低頻SMT振蕩器規格表
Standard Frequency
 FL 100.000 KHz
Supply voltage
VDD
 1.2~5.5 V
Frequency tolerance
 ΔF/F ±20 ppm
Current consumption (typ./max.)
IDD
0.65 / 0.85
µA
Duty cycle (min./max.)

40 / 60
 %
Start up time (max.)
tstart
0.5
S
Voltage coefficient (max.)

±1.5
ppm/V
Aging first year max. @ 25°C
ΔF/F
±3
ppm
Turnover temperature (typ.)
T0
18 ±5
°C
Frequency vs. temperature
ΔF/F0
–0.035 ppm/ °C² (T - T0)2 ±10%
 ppm
Storage temperature range
T_stg
 −55~+125
°C
TA Operating temperature range
 T_use −40~+85 °C
Shock resistance

5000 g, 0.3 ms, ½ sine

Vibration resistance

20 g / 10–2000 Hz


MICRO晶振|OM-0100-C7-20ppm-TA-QC|低頻SMT振蕩器尺寸圖

制造商零件編號 制造商 描述
OV-7604-C7-32.768k-20PPM-TB-QA Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+125C AEC-Q200
OV-7604-C7-32.768kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+85C
MS1V-T1K-32.768kHz-12.5pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-7pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-100 PPM -40/+85C
CM8V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
MS1V-T1K-32.768kHz-7pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CC4V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CC5V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CC5V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
OV-0100-C7-100.000kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 100.0 kHz +/-20 PPM -40/+85C
OM-0100-C8-100.00kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 100.0 kHz +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CC7V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
MS3V-T1R-32.768kHz-12.5pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
MS3V-T1R-32.768kHz-7pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CC7V-T1A-32.768kHz-7pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-100 PPM -40/+85C
CC7V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768k-12.5pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM8V-T1A-32.768k-9pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+125C
MS1V-T1K-32.768kHz-10pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 10.0 pF +/-20 PPM -40/+85C
CC5V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
OM-7605-C8-32.768kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+85C
OM-7604-C7-32.768kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM I2C -40/+85C
MS3V-T1R-32.768kHz-9pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
CM7V-T1A-Low-ESR-32.768kHz-9pF-20-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM LOW ESR
CC7V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CM7VT1A-LowESR-32.768kHz-12.5pF-20-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM LOW ESR
CM7V-T1A-Low-ESR-32.768kHz-7pF-20-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM LOW ESR
CM7V-T1A-32.768k-12.5pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768k-7pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768k-7pF-100PPM-TB-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-100 PPM AEC-Q200
CC7V-T1A-32.768k-9pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768kHz-12.5pF-100PPM-TC-QC Micro Crystal 晶體 32.768 kHz 12.5 pF 100 PPM -55/+125C
CC4V-T1A-32.768kHz-12.5pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+85C
CM7V-T1A-32.768k-12.5pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768k-9pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768k-7pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768kHz-9pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -55/+125C
CC7V-T1A-32.768k-12.5pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM7V-T1A-Low-ESR-32.768kHz-6pF-20-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM LOW ESR
CM7V-T1A-32.768kHz-6pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768k-7pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768k-9pF-100PPM-TC-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM AEC-Q200
CM7V-T1A-32.768k-9pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768k-12.5pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768kHz-6pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-10 PPM -40/+85C
CC4V-T1A-32.768kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM -40/+85C
CM8V-T1A-32.768kHz-6pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768kHz-12.5pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+125C
CC4V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768kHz-7pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+125C
CC4V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
CM9V-T1A-32.768kHz-7pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-100 PPM -40/+85C
CM9V-T1A-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+85C
CC5V-T1A-32.768kHz-12.5pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+125C
CC5V-T1A-32.768kHz-7pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+125C
CM7V-T1A-0.3-32.768kHz-7pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM 0.3mm
CM7V-T1A-0.3-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM 0.3mm
CM7VT1A-0.3-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM 0.3mm
CM7V-T1A-100.000kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 100.000 kHz 9.0 pF +/-100 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+85C
CM7V-T1A-32.768kHz-9pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-10 PPM -40/+85C
CM9V-T1A-32.768kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -40/+125C
CM7V-T1A-32.768kHz-7pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+125C
CC7V-T1A-32.768k-12.5pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768kHz-12.5pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+85C
CC7V-T1A-32.768kHz-12.5pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -55/+125C
CM9V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
202684-MC03 Micro Crystal 晶體 32.768 kHz 4.0 pF +/-20 PPM -40/+85C
CM7V-T1A-32.768kHz-7pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-10 PPM -40/+85C
202273-EA00 Micro Crystal 標準時鐘振蕩器 128MHz 20ppm -55C +85C
MS1V-T1K-32.768kHz-9pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
MS1V-T1K-32.768kHz-6pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM -40/+85C
OV-7604-C7-32.768kHz-20PPM-TB-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+125C
CM7V-T1A-32.768kHz-12.5pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -55/+125C
CM7V-T1A-32.768k-12.5pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CM8V-T1A-32.768k-12.5pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768kHz-7pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM -40/+125C
CM8V-T1A-32.768kHz-9pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+125C
CM7V-T1A-32.768k-9pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768kHz-9pF-20PPM-TB-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+125C
CM7V-T1A-32.768k-12.5pF-10PPM-TA-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-10PPM-TB-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+125C
CC7V-T1A-32.768k-9pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768kHz-9pF-10PPM-TB-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-10 PPM -40/+125C
CC7V-T1A-32.768kHz-9pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -55/+125C
CM8V-T1A-32.768kHz-7pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-100 PPM -40/+85C
CM8V-T1A-32.768kHz-12.5pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -55/+125C
CC7V-T1A-32.768kHz-12.5pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-100 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-100 PPM -40/+85C
CC7V-T1A-32.768kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM -40/+85C
CC7V-T1A-32.768kHz-9pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-10 PPM -40/+85C
CM7V-T1A-Low-ESR-32.768k-7pF-10-TB-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-10 PPM LOW ESR
CC7V-T1A-100.000kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 100.000 kHz 9.0 pF +/-100 PPM -40/+85C
CM7V-T1A-32.768kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM -40/+85C
CM7V-T1A-32.768kHz-12.5pF-100PPM-TB-QC Micro Crystal 晶體 32.768 kHz 12.5 pF 100 PPM -40/+125C
CM7V-T1A-Low-ESR-32.768k-9pF-20-TB-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM LOW ESR
CC7V-T1A-32.768k-9pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CC7V-T1A-32.768kHz-7pF-10PPM-TA-QC Micro Crystal 晶體 32.768 kHz 7.0 pF +/-10 PPM -40/+85C
CM7V-T1A-32.768k-9pF-100PPM-TC-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM AEC-Q200
CC4V-T1A-32.768kHz-6pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM -40/+85C
CM8V-T1A-32.768kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM -40/+85C
CC5V-T1A-32.768kHz-6pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM -40/+85C
CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 100.000 kHz 9.0 pF +/-100 PPM -40/+85C
CM7V-T1A-32.768k-6pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 6.0 pF +/-20 PPM AEC-Q200
MS1V-T1K-32.768kHz-12.5pF-10PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 12.5 pF +/-10 PPM -40/+85C
OV-7605-C8-32.768kHz-20PPM-TA-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+85C
CC1V-T1A-1.8432MHz-10pF-500PPM-TC-QC Micro Crystal 晶體 1.8432 MHz 10.0 pF 500 PPM -55/+125C
OM-7604-C7-32.768kHz-20PPM-TB-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+125C
CC4V-T1A-32.768k-9pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
MS1V-T1K-32.768kHz-6pF-10PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 6.0 pF +/-10 PPM -40/+85C
OV-7604-C7-32.768k-10PPM-TB-QA Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-10 PPM -40/+125C AEC-Q200
OV-7604-C7-32.768k-20PPM-TA-QA Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-20 PPM -40/+85C
CC4V-T1A-1.000MHz-10pF-100PPM-TA-QC Micro Crystal 晶體 1.000 MHz 10.0 pF +/-100 PPM -40/+85C
CC4V-T1A-153.600kHz-9pF-30PPM-TA-QC Micro Crystal 晶體 153.600 kHz 9.0 pF +/-30 PPM -40/+85C
CC1V-T1A-307.20kHz-4pF-100PPM-TC-QC Micro Crystal 晶體 307.200 kHz 4.0 pF 100 PPM -55/+125C
CC1V-T1A-1.8432MHz-10pF-100PPM-TA-QC Micro Crystal 晶體 1.8432 MHz 10.0 pF +/-100 PPM -40/+85C
CC1V-T1A-1.8432MHz-10pF-100PPM-TC-QC Micro Crystal 晶體 1.8432 MHz 10.0 pF 100 PPM -55/+125C
CC4V-T1A-40.000kHz-12.5pF-20PPM-TA-QC Micro Crystal 晶體 40.0000 kHz 12.5 pF +/-20 PPM -40/+85C
CC4V-T1A-32.768k-12.5pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CC4V-T1A-32.768k-12.5pF-20PPM-TC-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
CC4V-T1A-32.768kHz-9pF-10PPM-TC-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-10 PPM -55/+125C
CC1V-T1A-32.768kHz-9pF-100PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-100 PPM -40/+85C
CC1V-T1A-32.768kHz-9pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM -40/+85C
CC1V-T1A-1.8432MHz-10pF-500PPM-TA-QC Micro Crystal 晶體 1.8432 MHz 10.0 pF +/-500 PPM -40/+85C
CC1V-T1A-1.2288MHz-10pF-100PPM-TA-QC Micro Crystal 晶體 1.2288 MHz 10.0 pF +/-100 PPM -40/+85C
CC1V-T1A-1.2288MHz-10pF-100PPM-TC-QC Micro Crystal 晶體 1.2288 MHz 10.0 pF 100 PPM -55/+125C
CC1V-T1A-40.000kHz-9pF-30PPM-TC-QC Micro Crystal 晶體 40.000 kHz 9.0 pF +/-30 PPM -55/+125C
CC4V-T1A-32.768k-9pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
CC4V-T1A-32.768k-12.5pF-20PPM-TA-QA Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200
MS1V-T1K-32.768kHz-8.2pF-20PPM-TA-QC-Au Micro Crystal 晶體 32.768 kHz 8.2 pF +/-20 PPM -40/+85C
CC4V-T1A-32.768kHz-12.5pF-20PPM-TC-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-20 PPM -55/+125C
CC4V-T1A-32.768kHz-10pF-20PPM-TA-QC Micro Crystal 晶體 32.768 kHz 10.0 pF +/-20 PPM -40/+85C
OV-7604-C7-32.768kHz-10PPM-TA-QC Micro Crystal 標準時鐘振蕩器 32.768 kHz +/-10 PPM -40/+85C
OV-0100-C7-100.000kHz-50PPM-TA-QC Micro Crystal 標準時鐘振蕩器 100.0 kHz +/-50 PPM -40/+85C
CC1V-T1A-307.20kHz-4pF-100PPM-TA-QC Micro Crystal 晶體 307.200 kHz 4.0 pF +/-100 PPM -40/+85C
CC1V-T1A-32.768kHz-12.5pF-30PPM-TA-QC Micro Crystal 晶體 32.768 kHz 12.5 pF +/-30 PPM -40/+85C
CC1V-T1A-32.768kHz-9pF-30PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-30 PPM -40/+85C
CC1V-T1A-32.768kHz-9pF-15PPM-TA-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-15 PPM -40/+85C
CC1V-T1A-32.768kHz-9pF-30PPM-TC-QC Micro Crystal 晶體 32.768 kHz 9.0 pF +/-30 PPM -55/+125C
CC1V-T1A-1.000MHz-10pF-100PPM-TA-QC Micro Crystal 晶體 1.000 MHz 10.0 pF +/-100 PPM -40/+85C
CC1V-T1A-2.000MHz-10pF-100PPM-TA-QC Micro Crystal 晶體 2.000 MHz 10.0 pF +/-100 PPM -40/+85C
CC1V-T1A-40.000kHz-9pF-30PPM-TA-QC Micro Crystal 晶體 40.000 kHz 9.0 pF +/-30 PPM -40/+85C
200125-PL08 Micro Crystal 晶體 32.768kHz 7pF +/-10 PPM -40C +85C
OM-7605-C8-20PPM-TA-QA Micro Crystal 標準時鐘振蕩器 32.768kHz 20ppm 1.6-5.5V
CM7V-T1A-32.768kHz-7pF-20PPM-TB-QA Micro Crystal 晶體 32.768 kHz 7.0 pF +/-20 PPM AEC-Q200
CM7V-T1A-32.768k-9pF-20PPM-TA-QA T3 Micro Crystal 晶體 32.768 kHz 9.0 pF +/-20 PPM AEC-Q200
公司：深圳市億金電子有限公司
SHENZHEN YIJIN ELECTRONICS CO;LTD
電話：0755-27876565
手機：18924600166
QQ：857950243
郵箱：[email protected]
網站：http://www.lbfp.com.cn
地址：廣東省深圳市寶安區新安107國道旁

相關產品

誠征下列地區 晶振 | 石英晶振 | 圓柱晶振 | 貼片晶振 | 陶瓷晶振 | 石英晶體諧振器 | 頻率元件 的合作伙伴：
深圳市 廣州市 北京 上海 東莞 佛山 中山 順德 珠海 杭州 溫州 武漢 長沙 南京 大連 長春 西安 鄭州 澳門 沈陽 南寧 昆明 濟南 重慶 成都
kf
kf
close
kf 億金微信號
主站蜘蛛池模板： 色www永久免费 | 99久久久国产精品免费调教 | 甜性涩爱bt下载 | 一本二卡三卡四卡乱码麻豆 | 神马电影院午夜神福利在线观看 | 超碰免费视频公开观看 | 无码日韩人妻精品久久蜜桃免费 | 亚洲男人在线观看 | 国产三级在线观看视频 | 18动漫在线观看 | 黑人强伦姧人妻日韩那庞大的 | 亚洲精品无AMM毛片 亚洲精品网址 | 久久亚洲免费视频 | yellow日本动漫观看免费 | 久久伊人男人的天堂网站 | 亲胸吻胸添奶头GIF动态图免费 | WWW久久只有这里有精品 | u15女少天堂写真 | 99国产精品久久人妻 | 免费无码又爽又黄又刺激网站 | 成人国产在线看不卡 | 医生含着我的奶边摸边做 | 日韩一区二区三区精品 | 久久精品美女久久 | 无码AV精品一区二区三区 | WWW夜片内射视频在观看视频 | 亚洲欧洲精品成人久久曰影片 | 无人区国产片 | 麻豆成人啪啪色婷婷久久 | 免费精品国偷自产在线在线 | 热综合一本伊人久久精品 | 日日啪在线影院百度 | www亚洲欲色成人久久精品 | 高清无码色大片中文 | 婷婷综合亚洲爱久久 | 狠狠操伊人 | 男人狂躁进女人免费视频公交 | 国产精品久久久久久久久爆乳 | 神电影院午夜dy888我不卡 | 邓奴的视频IVK | 5g在视影讯天天5g免费观看 |
